High Temperature Tungsten Carbide Sleeves For Aerospace Engineering
Product Details:
| Place of Origin: | SICHUAN CHINA |
| Brand Name: | Xinsheng |
| Model Number: | customized |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 Pcs |
|---|---|
| Price: | 20-400USD |
| Packaging Details: | Packed In Paper Box |
| Delivery Time: | 35 Working Days |
| Payment Terms: | L/C,T/T,Western Union |
| Supply Ability: | 500000 Pcs Per Month |
|
Detail Information |
|||
| Material: | 100% Virgin Tungsten Carbide | Product Name: | Tungsten Carbide Sleeve Bushing |
|---|---|---|---|
| Size: | OEM Accepted | Highlight: | High Temperature Tungsten Carbide Sleeves, Aerospace Engineering Tungsten Carbide Sleeves |
| Highlight: | aerospace engineering tungsten carbide parts,aerospace engineering tungsten carbide sleeves,oem tungsten carbide parts |
||
Product Description
High Temperature Tungsten Carbide Sleeves for Aerospace Engineering
Description
Tungsten Carbide Sleeves are vital components widely employed across diverse industrial domains, prized for their durability and extended service life. Fabricated from tungsten carbide, these cylindrical sleeves demonstrate outstanding hardness and density, rendering them highly resistant to wear and deterioration. Their sturdy composition makes them well-adapted for environments characterized by extreme temperatures and pressures. In the domain of oilfield operations, Tungsten Carbide Sleeves play pivotal roles in ensuring integrity and operational efficiency. They establish secure seals that effectively prevent fluid and gas leakage in oil wells, thereby enhancing operational safety and reliability. Furthermore, these sleeves exhibit non-magnetic properties and possess a low coefficient of friction, rendering them ideal for high-pressure conditions. Their exceptional resistance to corrosion further bolsters their suitability for drilling, production, and storage operations, underscoring their versatility and reliability in demanding industrial settings.
| Grade | ISO Grade | Chemical Composition | Physical Properties | Applications | |||||||
| WC% | CO% | Density g/cm3(±0.1) | Hardness HRA(±0.5) | TRS Mpa(min) | Grain Size(μ m) | ||||||
| YG6 | K20 | 94 | 6 | 14.85-15.00 | 90.5-92 | 1800 | 1.2-1.6 | Carbide burr. | |||
| YG6X | K15 | 94 | 6 | 14.80-15.00 | 91.7-93 | 1600 | ＜1.0 | High wear resistance and higher, strength. Machining of chilled alloy cast irons and refractory alloy steel or finishing of common cast irons. | |||
| YG8 | K30 | 92 | 8 | 14.62-14.82 | 89.5-91 | 1900 | 1.2-1.6 | Wire drawing die and non-standard structure and mechanical component and valve ball. | |||
| YG9 | K40 | 91 | 9 | 14.40-14.60 | 89-90 | 1850 | 1.2-1.6 | Flow sleeves, bushings, rings. | |||
| YG9C | K40 | 91 | 9 | 14.50-14.90 | 87.5-89 | 1815 | 1.2-1.6 | Nozzles, for the petroleum. | |||
| YG11 | K40 | 89 | 11 | 14.35 | 89 | 3200 | 1.6-2.0 | Nozzle, buttons, hemisphere, drilling teeth for the petroleum industry. | |||
| YG11C | - | 89 | 11 | 14.20-14.40 | 87.5-89 | 2200 | 1.6-2.4 | Inserts for mining and high-pressure nozzles in the petroleum, chemical, and mechanic industries. | |||
| YG13 | - | 87 | 13 | 14.10-14.30 | 87.5-89 | 2500 | 1.6-2.0 | Sleeves and bushings. | |||
| YG13C | - | 87 | 13 | 14.05-14.25 | 85.8-87.3 | 2550 | 2.4-4.0 | Alloy teeth and brazing bits. | |||
Competitive Pros
- Thermal Stability: These sleeves maintain their structural integrity and performance even at elevated temperatures, ensuring consistent operation in demanding thermal environments.
- Low Coefficient of Friction: Tungsten carbide sleeves feature a low coefficient of friction, reducing energy consumption and minimizing heat generation during operation.
- Precision Engineering: Manufactured with precision engineering techniques, tungsten carbide sleeves offer tight tolerances and dimensional accuracy, ensuring seamless integration into complex machinery and systems.
- Versatility: Tungsten carbide sleeves are versatile components suitable for a wide range of applications, including pump shafts, valve stems, and rotary seals.
- Enhanced Efficiency: By minimizing downtime due to maintenance and replacements, tungsten carbide sleeves contribute to increased operational efficiency and productivity.
FAQ
1. Q: What payment methods do you accept?
A: We accept payment by bank transfer and Western Union.
2. Q: What is the benefit of using Tungsten Carbide Sleeves?
A: Tungsten carbide sleeves improved wear resistance, increased strength and durability, and improved corrosion resistance. They are also more dimensionally stable than other materials and can withstand higher temperatures, making them suitable for use in a wide range of applications.
3. Q: Can Tungsten Carbide Sleeves be customized?
A: Yes, Tungsten Carbide Sleeves can be customized to meet specific size, shape, and tolerance requirements based on the application needs.
